LINSN Control Receiver RV908M
integrated with 12 standard hub75-type connectors
supports up to 384*512pixels
up to 24 sets of RCG data
integrated with 12 standard hub75-type connectors
supports up to 384*512pixels
up to 24 sets of RCG data
Functions and features:
Single card can support 24 group of RGB data output mode
2. Maximum supports 384X512 pixels (Please note that there are recommended values depending on the design of LED screen)
3. Supports brightness calibration pixel by pixel and single-card color space conversion
4. Supports network cable BER test
5. Supports configuration file read back
6. Supports 138 decode, 595 serial decode and so on
7. Realizes high refresh and high gray level effect
| Capacity | 384X512 Pixels |
| Input Voltage | DC4.5V ~ 5.5V |
| Rated power consumption | 3W |
| Temperature | -20℃~ 70℃ |
Humidity | 0% ~ 95% |
| Dimensions | 144.0 X 91.2mm |
| Weight | 99g |
| Packing Info | Each card packed with small red foam bag, and 100pcs per carton |
The LINSN Control Receiver RV908M is a high-performance LED receiving card designed for stable signal transmission and precise display control. Integrated with 12 standard HUB75 connectors, it offers flexible connectivity and efficient installation for various indoor and outdoor LED display projects.
With a maximum loading capacity of 384×512 pixels, the RV908M ensures smooth performance, high refresh rates, and excellent grayscale processing. It is suitable for fixed installations, commercial LED screens, rental displays, and stage applications.
As part of a complete control solution from LISN LED, the RV908M delivers reliable performance and strong compatibility for professional LED display systems.
Supports up to 24 groups of RGB data output
Maximum load capacity: 384×512 pixels (recommended value depends on screen design)
Integrated 12 HUB75 standard interfaces
Pixel-by-pixel brightness calibration
Single-card color space conversion
Supports network cable BER test
Supports configuration file read-back
Compatible with 138 decode, 595 serial decode, and more
High refresh rate and high grayscale performance
Capacity: 384×512 pixels
Input Voltage: DC 4.5V–5.5V
Rated Power Consumption: 3W
Operating Temperature: -20℃ to 70℃
Humidity: 0%–95%
Dimensions: 144.0 × 91.2 mm
Weight: 99g
Packing: 1 card per foam bag, 100 pcs per carton
1. What is the maximum pixel capacity of the RV908M?
The RV908M supports up to 384×512 pixels per card. Actual recommended loading depends on the LED screen design and module configuration.
2. Does the RV908M support brightness calibration?
Yes, it supports pixel-by-pixel brightness calibration to improve display uniformity and image quality.
3. Can the RV908M test network cable quality?
Yes, it supports network cable BER (Bit Error Rate) testing to ensure stable signal transmission.
4. What types of decoding does it support?
The card supports 138 decode, 595 serial decode, and other common decoding methods for flexible module compatibility.
5. Is the RV908M suitable for high refresh LED screens?
Yes, it supports high refresh rates and high grayscale levels, making it suitable for applications requiring smooth visuals and clear image performance.
